CNC flat bed lathe with FAGOR 8055iA TC control with conversational programming' 3.38” spindle bore, D1-8 camlock spindle built on one piece casting bed.

CNC Lathe - Sharp model 1740CNC

SHARP CNC Lathes

1740NC, 1760NC, 1780NC: 17" swing over bed, 7.5" Swing Over Cross Slide, 10HP.
Click to Request a formal Quote for the 17 inch size Sharp CNC Lathe Machine
2040NC, 2060NC, 2080NC: 20" swing over bed, 12.5" Swing Over Cross Slide, 10HP.
Click to Request a formal Quote for the 20 inch size Sharp CNC Lathe Machine
2240NC, 2260NC, 2280NC: 22" swing over bed, 13.2" Swing Over Cross Slide, 10HP.
Click to Request a formal Quote for the 22 inch size Sharp CNC Lathe Machine

• Each machine is available with 40", 60" or 80 inch distance between centers.
• Flat bed CNC lathe with FAGOR 8055iA control and drive system
• User friendly conversational programming language
• Different modes of operations available
• Operate as manual lathe with electronic handwheels,
• Operate as a full CNC lathe with programmable speed, using conversational language or G code language,
• Operate semi automatically, combining manual and CNC operations
• Teaching in mode
• OEM 2-axis CNC, 12 lin. TFT CNC Chassis & USB driver. Std 20 inputs/12 outputs
• D1-8 camlock spindle, 3-3/8” spindle bore
• Geared head with 3 steps speed change, programmable speed
• One Piece Cast Meehanite Bed
• 10 HP Spindle Motor

CNC CONTROL 8055i/A by Fagor:
OPERATING MODES:
• Manual – the lathe is operated like a conversational lathe, using the 2 electronic handwheels in the front to move the axes. In addition if offers convenient features such as digital readout and constant surface speed.
• Semiautomatic – it allows 2 axes to be controlled with the cranking of 1 handwhel, the machinist can cut arcs, tapers and chamfers.
• Automatic – with ability to execute any program, plus background editing capability. Powerful tool inspection mode included as well as full program control from keyboard programs to choose from, the 8085i/A will control everything from start to finish.
• Single step – the machinist can go through all or part of the process by executing the program step by step.

PROGRAMMING LANGUAGE:
• Conversational – icon key with conversational graphic screens for easy operator data input. No prior programming experience needed
• G-code – this programming enables utilization of some sophisticated features such as parametric or variable programming. Auto –prompt via the help key prompts operator though graphic & text help screens.

PROGRAMMING TOOLS:
• Teach-in mode – the first part can be made manually while the control records the corresponding program, and then additional parts can be made in automatic mode.
• Canned Cycles – by selecting the associated ICON key or G-code, the CNC will prompt you through all canned cycles including Turning, Facing, Grooving and Threading, All equipped with a Thread Repair Canned Cycle.
• On-board profile editor for easy blue print programming. Simply enter the data right off the blueprint, the CNC automatically creates the program including complex profiles.
• Solid graphic as standard with tool shape representation standard and available for use in both Execution and Simulation mode, Also with line graphic capability.

STANDARD EQUIPMENT:
• Back Plate
• Coolant pump equipment
• Automatic lubrication system
• Timing belts
• Safety guard ( include: Rear Splash guard, 2-Sliding doors in front )
• Electrical box to suit
• CNC Turning Control
• Safety Chuck guard
• Mounting block for toolpost
• Halogen Work Lamp
• Encoder for Spindle RPM
• Electronic handwheel X & Y Axis
• Main motor 10HP Electrical
• 4-way toolpost
• Toolbox and adjusting tools
• Centering sleeve MT#7 x MT#5
• Two dead centers
• Camlock spindle wrench
• Screw driver Spanner ( double-ended wrench )
• Hexagonal wrench
• Operation manual

SPECIFICATIONS:

  Sharp 17 inch CNC Sharp 20 inch CNC Sharp 22 inch CNC
Swing Diameter Over Bed 17-5/16" 20" 22”
Swing Over Cross Slide 7-1/2" 12-1/4" 13.2”
Height of Center 8-5/8" 11" 8-5/8”
Distance Between Centers choose 40, 60 or 80 choose 40, 60 or 80 choose 40, 60 or 80
Max. Turning Length 35" / 55" / 75" 35" / 55" / 75" 35" / 55" / 75"
BED:
Width of Bed Ways 13" 13" 13"
Swing Over Gap 26" 30-3/4" 26"
Length of Gap 11-3/4" 11-3/4" 11-3/4"
Width in front of Face Plate 7-1/2" 6-3/4" 7-1/2"
SPINDLE:
Spindle Bore 3-3/8" 3-3/8" 3-3/8"
Bar Capacity 3-1/4" 3-1/4" 3-1/4"
Spindle Nose Type D1-8 Camlock D1-8 Camlock D1-8 Camlock
Taper of Spindle Bore MT#7 MT#7 MT#7
Taper of Center MT#5 MT#5 MT#5
Spindle Speeds (3 steps) 10-84 rpm, 45-380 rpm, 240-2000 rpm 10-60 rpm, 30-300 rpm, 180-1500 rpm 10-84 rpm, 45-380 rpm, 240-2,000 rpm
Bearing Type 3 Points Supported 3 Points Supported 3 Points Supported
Bearing Size 2 Taper Roll Bearing #32024 & #32022; 1 Ball Bearing #6021 (Rear End) 2 Taper Roll Bearing #32024 & #32022; 1 Ball Bearing #6021 (Rear End) 2 Taper Roll Bearing #32024 & #32022; 1 Ball Bearing #6021 (Rear End)
TRAVEL / BALLSCREWS
Cross Slide Travel (X axis) 11" 11" 11"
Ballscrew Diameter (X axis) 1" 1" 1"
Rapid Travel (X axis) 236 in/min. 236 in/min. 236 in/min.
Axis Motor (X axis) Yasakawa 200V 0.9Kw; AC Servo Yasakawa 200V 0.9Kw; AC Servo Yasakawa 200V 0.9Kw; AC Servo
Driver (X axis) Yasakawa Yasakawa Yasakawa
Longitudinal Travel (Z axis) 36-1/4” 36-1/4” 36-1/4”
Ballscrew Diameter (Z axis) 1-1/2” 1-1/2” 1-1/2”
Rapid Travel (Z axis) 315 ipm 315 ipm 315 ipm
Drive Motor (Z axis) Yasakawa 200V 1.3Kw; AC Servo Yasakawa 200V 1.3Kw; AC Servo Yasakawa 200V 1.3Kw; AC Servo
TAILSTOCK
Quill Diameter 3" 3" 3"
Quill Taper MT#5 MT#5 MT#5
Quill Travel (graduated) 6-5/16" 6-5/16" 6-5/16"
MAIN MOTOR
Main Spindle Motor
220 or 440 Volts
10 hp, 3-Phase Continuous Rating Induction Motor 10 hp, 3-Phase Continuous Rating Induction Motor 10 hp, 3-Phase Continuous Rating Induction Motor
Invertor Yasakawa 220V 10HP Yasakawa 220V 10HP Yasakawa 220V 10HP
MACHINE SIZE
Dimensions (LxWxH) 118 x 60 x 70 inches 148 x 60 x 75 inches 118 x 60 x 70 inches
Machine Weight 4409 Lbs. 6160 Lbs. 4409 Lbs.
